Raffaello

Hand modelled steel coating
Front glass door with black etching
Space-saving
Forced ventilation
Pellet tank underneath the combustion chamber
5 operating power levels
Menu display in 6 languages
Self-supporting quick to install structure
Removable handle
Upper - rear smoke extraction
Radio control supplied
Safety thermostat
Suitable for external thermostat
Safety Manostat
Timer Thermostat

Total heat output: max 11,5 kW – min 4,8 kW
Nominal heat output: max 10,0 kW – min 4,5 kW
Energy efficiency class: A+
Efficiency: Pmax 88,5% – Pmin 93,0%
CO emission at 13% O2: Pmax 0,014% - Pmin 0,019%
Pellet consumption: max 2,4 kg/h - min 1,0 kg/h
Reservoir capacity: 13 kg
Heatable room volume: 180 – 270 mc
Minimum distances from flammable walls: front side: 100 cm
Voltage / Frequency: 230 V / 50 Hz
Rated input power: 410 W
Dimension: L 118 x P 67,7 x H 210,5 cm
Weight: 190 kg
Steel combustion chamber
Stainless steel brazier
Complies with: EN14785 - BImSchV II - 15a B-VG - LRV/VKF
Fume outlet: Top - Rear
Display: Radio control
Radio control: Included
WIFI module for remote control: Optional





Raffaello

CERTIFICATION

Certified and tested product.

ECODESIGN 2022

This product is in conformity with ECO DESIGN 2022 that sets the criteria defining sustainable engineering, computations and measurements aimed at reducing emissions in the atmosphere.

ENVIRONMENTAL CLASSIFICATION

This product complies with the most restrictive rules on environmnental standards and it has been awarded with 4 stars.

SHU

The SHU symbol indicates that the stove is equipped with a removable handle. This is a security feature to avoid accidental and/or involuntary opening of the fire door.

WI-FI MODULE (OPTIONAL)

Module for remote control, it can be installed during post-sales.
